Wuben X1 Pro – Power Meets Portability

Key Features Overview

• 12300 lumens ultra-high output
• 410m beam distance
• Dual-beam optical system (spot + flood)
• Replaceable 21700 battery design
• Reverse charging power bank function
• Detachable intelligent cooling fan
• Heavy-duty metal bike mount
• USB-C PD fast charging (30W)
• IP65 water & dust resistance

High Output Lighting Performance (Spot + Flood System)

The X1 Pro adopts a dual-beam architecture that blends long-range spotlight precision with wide-area flood illumination for maximum usability in outdoor environments.

• Beam Distance: 410 meters
• Peak Intensity: 42,025 cd
• Lighting Mode: Spot + Flood dual system

Why it matters:

• Long-range visibility for search and rescue
• Wide campsite illumination
• Balanced tactical and outdoor lighting coverage



Battery System & Power Management

• Battery: 2 × 21700 4800mAh (replaceable)
• Charging Interface: USB-C PD fast charging
• Max Input Power: 30W
• Full Charging Time: ~75 minutes

Reverse Charging Function

The X1 Pro supports reverse charging, which allows it to function as a portable emergency power source for small electronic devices.

Advanced Cooling System – Stable High Output Performance

• Intelligent temperature sensor system
• MCU-based thermal regulation
• Built-in cooling fan
• Detachable fan module design
• Power consumption: 0.3W

This system ensures stable brightness output during sustained high-lumen operation while protecting internal components and extending overall lifespan.

Upgraded Bike Mount System (Metal Reinforced)

• Zinc alloy reinforced structure
• High vibration resistance
• Improved durability for off-road riding
• More stable than plastic mounts

Ideal for:

• Motorcycle night riding
• Mountain biking
• Urban commuting safety lighting



Mounting Flexibility (1/4” Thread Support)

The integrated 1/4” thread supports multiple real-world usage scenarios, including tripods, light stands, campsite setups, repair lighting stations, and content creation environments.

User Interface & Functionality Operations

• Power On/Off: Press the main button once to turn on or off.
• Mode Selection Switch:
  • Left: Spotlight only
  • Middle: Spotlight + Floodlight
  • Right: Floodlight only
• Brightness Adjustment:
  • Press and hold to cycle through: Eco → Low → Medium → High → Eco
  • Release to lock brightness.
• Turbo Mode:
  • Double-click in any state to enter Turbo.
  • Double-click again to return to the previous mode.
• Eco Quick Start:
  • Hold the button while OFF to enter Eco mode directly.
• Strobe / SOS:
  • Triple-click to enter Strobe; triple-click again to switch between SOS and Strobe.
  • Single-click to exit.
• Lock / Unlock:
  • Quadruple-click while OFF to lock (the light flashes three times).
  • Quadruple-click again to unlock (Eco mode activates).
• Fan Control:
  • Auto: Activates when the temperature rises; stops when cooled.
  • Manual: Five clicks turn the fan ON/OFF; shuts off automatically after 5 minutes.
• Battery Indicator:
  • Blue steady: 100%–90%
  • Red steady: 90%–40%
  • Blue flash: 40%–15%
  • Red flash: <15% (low battery warning)

Design & Build

• Material: Aluminium alloy
• Cooling System: Modular, temperature-controlled 3W fan (replaceable)
• Airflow Design: Dual air inlet/outlet for effective heat dissipation
• Grip & Shape: Flat, ergonomic profile for comfort and control
• Mounting System: Solid zinc-alloy clip and rail for secure, no-slip accessory mounting.
• Battery Switch: With a locking mechanism for safety
• Port Cover: Sealed USB-C port for dust and splash resistance
• Rope Hole / Tail Loop: Compatible with carabiner or lanyard
• Waterproof Rating: IP65
