Design and Structure
The Wuben X4 showcases the brand’s continued evolution in product design and positioning. Measuring just 96mm × 35mm × 26mm (including the pocket clip), it boasts a remarkably compact and portable form factor.
Crafted through die-cast aluminum alloy construction and finished with an upgraded oil-spray coating, the X4 demonstrates refined detailing compared to the earlier X2 Pro. Its dual-tone color scheme—off-white and black—contributes to a clean, modern aesthetic. The matte finish offers a smooth, premium feel in hand, though it is slightly prone to fingerprint marks.
At the top of the flashlight sits the main light unit, featuring four LEDs arranged behind a hybrid lens system: three optimized for throw and one for flood, achieving an effective balance between long-distance and wide-area illumination.
On the front of the body, the auxiliary light is housed beneath a translucent, embedded PC diffuser that enhances floodlight diffusion. The LED layout follows a 6+1 configuration—six white LEDs for close-up tasks, and one RGB LED capable of cycling through seven vibrant colors: red, orange, yellow, green, cyan, blue, and purple.
Controls and Configuration



Accessory Compatibility and Expandability


Feature Highlights
1. Portability
The sturdy rear clip allows for easy attachment to a backpack, belt, or pocket, making the X4 easy to carry.
2. Battery Indicator
With the main or side light turned off, press and hold the button for 1 second to display battery status: blue indicates sufficient charge, red flashing signals low battery.
3. Charging
Slide the mode switch to moonlight mode to reveal the Type-C charging port. The X4 supports 5V/2.4A input and can fully charge in about 2.5 hours. It’s also compatible with solar charging panels, ideal for outdoor use.
4. Mode Switching
The mode slider toggles between Moonlight, Main Light, Side Light, and Lockout modes.
5. Lighting Controls
- Rotary switch: Press to turn on/off, rotate to adjust brightness.
- Tail switch: Provides momentary turbo, strobe, and quick access to moonlight mode.
6. Water Resistance
Rated IP68, the X4 performs reliably underwater and in harsh environments. Water-submersion tests confirmed stable operation and seamless mode switching.

Mode Details
Main Light Mode
Click the side switch to activate. Stepless brightness adjustment from 5 to 1500 lumens via the rotary dial. Double-click the side switch to access Turbo mode directly.
Side Light Mode
Click to activate; long-press toggles between white light and RGB modes.
- White light: 1–100 lumens stepless dimming
- RGB mode: Smooth rotation through seven colors, single-click to turn off
- RGB Beacon: After selecting a color, double-click to activate beacon; double-click again to exit
- RGB Strobe: From off-state, double-click the rotary switch to enter police-style strobe (red/blue, red/green, red/yellow)
Moonlight Mode
Access via Moonlight setting or single-click the tail button. 5 lumens brightness, ideal for close-range tasks at night.
Tactical Mode
From the off-state, single-click the tail button for instant turbo output (1500 lumens). Double-click to enter strobe mode, useful in emergency or self-defense situations.
